Peplink Balance SDX Pro
Modular SD-WAN Router with Edge Computing Capability


Peplink Balance SDX Pro
Peplink Products
Peplink Balance SDX Pro
Peplink Balance SDX Pro
SDX Pro Base Model, No Expansion module, 500GB SSD, 2x GE WAN/LAN Ports, 2x 10GE SFP+ WAN/LAN ports, 2x USB WAN
#BPL-SDX-PRO-M2
List Price: £5,999.00
Our Price: Request a Quote
Peplink Balance SDX Pro
SDX Pro Base Model, No Expansion module, 1TB SSD, 2x GE WAN/LAN Ports, 2x 10GE SFP+ WAN/LAN ports, 2x USB WAN
#BPL-SDX-PRO-M2-1TB
List Price: £6,279.00
Our Price: Request a Quote
Peplink Balance SDX Pro
SDX Pro Base Model, No Expansion module, 2TB SSD, 2x GE WAN/LAN Ports, 2x 10GE SFP+ WAN/LAN ports, 2x USB WAN
#BPL-SDX-PRO-M2-2TB
List Price: £6,649.00
Our Price: Request a Quote

More pricing below, click here!

Please Note: All prices displayed are Ex-VAT. 20% VAT is added during the checkout process.

Overview:

Modular SD-WAN Router with Edge Computing Capability

  • 2x FlexModules for Versatility and Futureproofing
  • Host Virtual Machines and Docker Containers
  • 24Gbps Throughput for Enterprise Deployments
  • Redundant Power Supplies for Uninterruptible Power

  • Ready-Built Infrastructure

    Your SDX Pro comes ready to connect to the SpeedFusion Cloud: a global network of secure endpoints with unique capabilities. Use the SpeedFusion Cloud as an unbreakable worldwide VPN, saving setup and maintenance costs.


    Ready for Anything

    Insert a cellular module and a GE or SFP+ module to provide cellular failover for branch networks. Insert a SIM Injector module to dynamically allocate up to 56 SIM cards. New FlexModules are in development, making this device futureproof.


    High Throughput

    The SDX Pro has enough throughput to handle any high-bandwidth enterprise branch or mobile deployment.


    Edge Computing Capable

    The SDX Pro is a one-box hosting solution that can deliver Docker containers, applications, and websites to its local network. By hosting resources near the network edge, you can reduce latency and make applications more responsive.

  • Websites
  • Virtual Machines
  • Dock Containers
  • Applications

  • Uninterruptible Power

    The SDX Pro is equipped with two power inputs and two hot-swappable power supplies. Only one of each is needed to function, ensuring continuous power delivery even if a cable gets disconnected or if a power supply drops out for any reason.


    Peplink Balance SDX Pro

    Specifications:


      Balance SDX Pro
    WAN Interface 2x 10G SFP+ Ports
    2x GE Ports
    2x USB 2.0 Ports for Secure OOBM
    2x FlexModules (Optional))
    Router Throughput 24 Gbps
    PepVPN / SpeedFusion Throughput No Encryption: 1 Gbps 256-bit AES: 600 Mbps
    Recommended Users 500-2000
    Max PepVPN/SpeedFusion Peers 800
    Power Input AC Input 100V - 240V
    Power Consumption 140W System
    420W PoE+ Power Budget
    Number of IPsec Tunnels 500
    802.1q VLANs Supported 1024
    Drop-In Mode Yes
    Recommended PPTP/L2TP/OpenVPN Users 500
    Maximum Number of APs Supported 2000
    High Availability Yes
    Dimensions 17.2 x 13.8 x 1.7 inches / 438 x 350 x 44 mm
    Weight (Modules) 80W, 330W PoE+ Power Budget
    Dimensions 17.2 x 13.3 x 1.7 inches | 438 x 340 x 44 mm
    Weight (No Modules) 15.9 pounds | 7.2 kg
    Operating Temperature 32° - 104°F / 0° - 40°C
    Humidity 10% - 85% (non-condensing)
    Certifications FCC, IC, CE
    Package Content SDX Pro Base Chassis
    1U 19″ Rack-mount Chassis
    1x Rubber Foot Pack
    2x Power Cords
    1x L-mount Set
    Warranty 1-Year Limited Warranty

    Documentation:

    Download the Peplink Balance SDX Pro Datasheet (PDF).

    It appears you don't have a PDF plugin for this browser. No biggie... you can click here to download the PDF file.
